线性模组使用本体与滑座一体成型钢材，改善线性模组原始铝滑座刚性较差的问题

大众彩票Actuator body and carriage are made from steel that can improve the rigidness of body and carriage

大众彩票● 线性模组不需拆卸钢带，即可由上往下固定或由下往上固定

大众彩票Canbe fixed from the top and bottom without removing the cover

● 直线模组本体侧面增加安装基准面承靠

大众彩票Mounting datum plane designed on the side of the body

大众彩票● 直线模组本体底部有定位PIN孔

Built in pin holes

直线模组采用特殊钢带结构设计，可减少发尘。电动滑台可用于洁净室内环境。

Special steel strip cover sealing design can prevent dirt and foreign objiects from penetrating inside

大众彩票直线模组轨道嵌入于本体后研磨，行走等高直线度可达±0.02mm

大众彩票Built in linear rail design, Straightness and Flatness are highly improved to ±0.02mm

宽度缩小，让设备安装所需空间更小

Rudeced width that can be fited in the compact environments.

自润滑结构设计，直线模组可实现轻负载30000km免维护

Self-lubricating design can achieve light load and 30000km maintenance free

大众彩票● 直线模组自润滑块有毛细作用始终储存和供给润滑油

大众彩票The self-lubricating block has a capillary action to always store and supply, the lubricating oil.

大众彩票● 直线模组自润滑块安装在密封端盖与滚动体之间，直接与沟道接触，润滑油供给在滚道上，当滚动体在沟道经过，起到润滑作用

大众彩票The self-lubricating block is installed between the sealing end cover and the rolling body, and is in direct contact with the channel, and the lubricating oil is supplied on the raceway, and the rolling body passes through the channel to provide lubrication.
